Junsi X8

Junsi X8
Swipe
Junsi X8Junsi X8Junsi X8Junsi X8
190,90 EUR
incl. VAT | excl. Shipping costs
Pcs
191 loyalty points. Infos about our Loyalty Points programme
Delivery Time: 1-3 days fr. 04.10.2023*
Product no.: Junsi iChargerX8
Do you have a question?
Due to the ElektroG2 / WEEE2, this item can only be purchased from buyers (end users) from Germany.

Junsi X8

Specifications

  • Microprocessor Controlled
  • 2.4 "IPS LCD Color Display - 320x240
  • Supported Battery Types: LiIo / LiPo / LiFe / LIHV / LTO / NiZn, NiMH / NiCd, Pb
  • Number of cells: 1-8 LiIo / LiPo / LiFe / LIHV / LTO / NiZn, 1-20 NiMH / NiCd, 1-15Pb ( 2-30 V)
  • Input voltage: DC 9-49 V
  • Input current: <35A
  • Charging power max .: 1100W from approx. 32V input voltage
  • Charging power at input voltage 12V:> 400W
  • Charging power at input voltage 24V: approx. 800W
  • Charging power at input voltage 30V: approx. 1000W
  • charging current : 0.05 - 30A
  • Discharge capacity max .: 50W
  • Discharge current: 0.05 - 30A
  • Regenerative discharge: up to 1100W
  • Discharge with external load max .: 1000W 33.5V / 30A
  • Balancing current: 2A per cell
  • automatic fan control - 1 fan
  • Micro USB port
  • Micro SD slot for storing logs and data
  • Dimensions: 97.5 × 64.5 × 37 ± 0.5m m
  • Weight: 200g
  • Storage of load programs and export to SD Card
  • Internal resistance measurement of cells
  • Servotest
  • Firmware update via USB connection possible.

Delivery:

  • Junsi iCharger X8
  • 1x output cable 3 , 3 mm² with XT60 socket
  • 1x input cable 3,3 mm² with XT60 socket
  • Installation CD with software

Weight
Weight 352g
